Armour & Weapons

Plate IX

Design for a suit of armour for Sir Henry Lee,
from the Almain Armourer’s Album.

After the fourteenth century the great helm was but seldom used for war, but for jousting it was still retained, and, as this form of military sport was practised more scientifically, so the weight and shape of the helm were made to suit the necessary conditions. The Brocas helm (Plate V) is the finest example of English helm of this period; it weighs 22 lb. The other known examples of home manufacture are the Westminster helm, which was discovered in the Triforium of Westminster Abbey in 1869, and weighs 17 lb. 12 oz.; the Dawtray helm at Petworth (21 lb. 8 oz.); the Barendyne helm at Haseley, near Thame (13½ lb.); the Fogge helm at Ashford, Sussex (24 lb.); the Wallace helm, in the collection at Hertford House (17 lb.); and the great headpiece in the possession of Captain Lindsay of Sutton Courtenay, Abingdon, which turns the scale at 25 lb. 14 oz. It will be seen from the weight of these helms that they could only be used for the jousting course and were put off on the first opportunity. The details of their construction have been noticed in Chapter III.

On referring to Plate V it will be seen that the bascinet was the precursor of the Salade, which may be considered the typical headpiece of the fifteenth century. The rear peak of the bascinet is prolonged over the neck, and in a later form of German origin the peak is hinged to allow the wearer to throw back his head with ease. The ocularium, or vision slit, is sometimes cut in the front of the salade, but more often it is found in a pivoted visor which could be thrown back. The Beavor is generally a separate piece strapped round the neck or, in tilting, bolted to the breastplate. Some writers call this the Mentonière, but this name should rather be applied to the tilting breastplate which also protected the lower portion of the face. Shakespeare uses the term beavor very loosely, and frequently means by it the whole helmet.

The German ‘Schallern’, or salade, so called from its shell-like form, seems to have been evolved from the chapel-de-fer or war-hat by contracting the brim at the sides and prolonging it at the back. In fact, in Chastelain’s account of the fight between Jacques de Lalain and Gérard de Roussillon the salade worn by Messire Jacques is described as ‘un chapeau de fer d’ancienne façon’.[23] The salade was often richly decorated. Baron de Cosson, in the preface to the Catalogue of Helmets exhibited at the Archaeological Institute in June, 1880[24], instances a salade made for the Duke of Burgundy in 1443, which was valued at 10,000 crowns of gold. More modest decoration was obtained by covering the salade with velvet and fixing ornaments over this of gilded iron or brass. There are several of these covered salades in the various collections in England and on the Continent. Sometimes the salade was painted, as we see in an example in the Tower.

The Armet, or close helmet, followed the salade, and is mentioned by Oliver de la Marche as early as 1443.[25] The name is supposed to be a corruption of ‘heaumet’, the diminutive of ‘heaume’, the great helm of the fourteenth century.[26] Whereas the salade is in form a hat-like defence, the armet fits the head closely and can only be put on by opening the helmet, as is shown on Plate V and Fig. 31. The various parts of the armet have been already described in Chapter III. The armet does not appear in monumental effigies in England before the reign of Henry VIII. The English were never in a hurry to take up new fashions in armour; being to a large extent dependent on the work of foreign craftsmen, they seem to have waited to prove the utility of an innovation before adopting it. Against this, however, we must place the fact that in the picture at Hampton Court of the meeting of Henry VIII and Maximilian, the English are all shown wearing armets, while the Germans still wear the salade. The armet on the Seusenhofer suit in the Tower, which has been noticed in this chapter, is a very perfect example of this style of headpiece.

The Burgonet is an open helmet, and, as the name implies, of Burgundian origin. To those students who consult Meyrick it is advisable to give a word of warning as to this author’s theory of the burgonet. He assumes that it is a variety of the armet, but with a grooved collar which fitted over the gorget. His authority for this assertion is a single reference in the Origines des Chevaliers Armoriés et Heraux, by Fauchet.[27] Space will not allow of the investigation of this authority, but Baron de Cosson in the Catalogue above quoted effectively disposes of Meyrick’s theory.[28] The salient points of the burgonet, as may be seen on Plate V, are the Umbril or brim projecting over the eyes, and the upstanding comb or (in some cases) three combs that appear on the skull-piece. In the best examples these combs are forged with the skull out of one piece of metal, a tour de force in craftsmanship that could hardly be surpassed. The ear-flaps are hinged at the sides, and at the base of the skull is fixed the Panache, or plume-holder. The faceguard, when used with the burgonet, is called the Buffe,[29] and, like the beavor worn with the salade, is held in place by a strap round the neck. This form of helmet was chiefly used by light cavalry.

The Morion and the Cabasset are both helmets worn by foot-soldiers, and appear about the middle of the sixteenth century. The cabasset is generally to be distinguished by the curious little point projecting from the apex. Often the comb and upturned brim of the morion are extravagant in form and tend to make the helmet exceedingly heavy and inconvenient.

The shields of the fifteenth and sixteenth century were more for display than for use, except in the tilt-yard. As we have seen, the development of plate armour, especially on the left side, made the shield not only unnecessary, but also inconvenient. In the joust, however, where it was important that the lance should find no hold on a vital part of the body, such as the juncture of the arm, the shield was used to glance the weapon off, or, where unhorsing was the object, it was ribbed with diagonally crossing ridges to give the lance-point a surer hold. The Pavis or Pavoise (Fig. 37) was more generally used by archers and crossbowmen as a cover. A good specimen of the pavis exists in the Ashmolean Museum at Oxford, and there are two large examples of heavier make with peepholes for the archer, and wooden props as shown in our illustration, at Brussels and Berlin.

Plate X

Horse armour of the Emperor Maximilian. Tower.

Photograph by Viscount Dillon.

CHAPTER V

We should remember, however, that Wace wrote in the second half of the twelfth century and, like the other chroniclers of the Middle Ages, both in picture and text, portrayed his characters in the dress of his own time. The Trapper of mail shown on Fig. 38 is taken from Stothard’s drawing of one of the paintings in the Painted Chamber at Westminster, now destroyed.[30] These decorations are supposed to have been executed about the year 1237. Here the horse is shown covered with a most inconvenient housing of mail, which can hardly have been in very general use, in this particular form at any rate; for it would be almost impossible for a horse to walk, let alone to trot or gallop, with such a defence. The textile trapper was, of course, lighter, and was used merely for ornament and display, though it may have been designed, as the surcoat was, to protect the mail defence beneath from wet.

Jean Chartier, in his Histoire de Charles VI (p. 257), states that sometimes these rich trappings or housings were, after the death of their owner, bequeathed to churches, where they were used for altar hangings, or inversely, when trappings were needed, the churches were despoiled of their embroideries to provide them.

The mailed horse appears as early as the Roman period, and is shown on the Column of Trajan, but in Europe he does not seem to have been commonly in use much before the thirteenth century. As the man was sometimes defended entirely by garments of quilted fabrics, so the horse also wore pourpointed housings. We can only surmise, from the folds and lines shown on seals or drawings, which variety is intended; but the stiff lines of the housing on the seal of Roger de Quinci, Earl of Winchester (1219-64), and its raised lozenges, seem to suggest a thicker substance than does the more flowing drapery on Fig. 11. Matthew Paris, in describing the Battle of Nuova Croce in 1237, writes that ‘A credible Italian asserted that Milan with its dependencies raised an army of six thousand men-at-arms with iron-clad horses’. An ordinance of Philip the Fair, in 1303, provides that every holder of an estate of 500 livres rental should furnish a man at-arms well mounted on a horse ‘couvert de couvertures de fer ou de couverture pourpointe’. The caparisoned horse first appears on royal seals in the reign of Edward I. In the Roll of Purchases of Windsor Park Tournament (1278), the horses are provided with parchment crests, and the Clavones or rivets used for fixing these crests are mentioned in the Wardrobe Accounts of Edward I in 1300: ‘cum clavis argenti pro eodem capello.’ The earliest note we have of a rigid defence for the horse is in the Windsor Roll, which contains the following item:—‘D Milon le Cuireur xxxviij copita cor de similitud’ capit equoz.’ This headpiece was of leather, either used in its natural state or as cuirbouilli, and seems to be the material suggested in the ivory chessman (Fig. 39) illustrated in Hewitt (vol. ii, p. 314). In the Will of the Earl of Surrey (1347) is mentioned a breastpiece of leather for a horse. In the fifteenth century we find the horse protected with plate like his rider, and usually the lines of the Barding or horse armour follow those of the man. Fig. 40 shows the armed horse with the various portions of his defence named.

The Chamfron is sometimes provided with hinged cheek-plates and usually has a holder for a plume. On the forehead are often shown the arms of the owner or a tapered spike. Angellucci, in his preface to the Catalogue of the Turin Armoury, differentiates between the chamfron (tesera) and the Frontale or plate protecting the front of the head alone. There are fine suits of Gothic horse armour both in the Musée d’Artillerie in Paris and also in the Wallace Collection at Hertford House. The latter is one of the best-arranged mounted suits in existence. The different pieces of the horse armour bear the delicate sweeping lines embossed on the surface in the same way that the armour of the man is treated. The restored linings of leather and skin show how the horse was protected from the chafing of the metal. The Peytral or Poitrel is hung from the neck and withers, and is frequently provided with large bosses, called Bossoirs, Pezoneras, or Glancing-knobs, to direct the lance-thrust away from the horse. It is often hinged in three pieces. The Flanchards hang from the saddle on either side, and are sometimes, as on Plate IV and the Frontispiece, curved upwards in the centre to admit of the use of the spur. The back of the horse is protected by the Croupière or Crupper, which is made up of several pieces riveted or hinged together. The root of the tail is covered by a tubular plate called the Gardequeue, which is often moulded into the form of a dragon or dolphin. All these plates were lined with leather or wadded with cotton to prevent chafing. Often, however, cuirbouilli was used instead of metal and was richly decorated with painting and gilding. A picture of the Battle of Pavia in the Ashmolean Museum, Oxford, shows many of these painted bards, and the same material is doubtless intended in the relief of the Battle of Brescia on the Visconti monument at Pavia. These leather bards have entirely disappeared and are not to be found in any collections except for a portion of a crupper of this material in the Tower. The saddle, with its high Arciones or peaks, back and front, was in itself an efficacious protection for the waist and loins. The term Cantle is sometimes used for either plate, but it is generally accepted as the name for the rear peak. Both this part and the front plate are often covered with metal. The great jousting saddles have been noticed in the preceding chapter. The reins are protected from being cut by hinged plates, as shown on Plate X.[31]

These pieces constitute the armour of the horse as usually found in museums and in painting and sculpture. There is, however, in the Zeughaus in Vienna a curious portrait of Harnischmeister Albrecht, dated 1480. The horse on which he rides is armed completely with plate except for an aperture in the flanchards for using the spur. The legs are covered with hinged and bolted defences very similar to those of the armour for men. It might be supposed that this was but a fantastic idea of the painter, if Viscount Dillon had not discovered a Cuissard, or thigh-piece, which much resembles those shown on the picture, in the Musée de la Porte de Hal, Brussels. In the days of the Decadence, when the craft of the armourer was to a great extent overwhelmed by the riotous fancy of the decorator, the horse shared with his rider in this display. The armour shown on Plate X, known as the Burgundian armour from the badges of the Emperor Maximilian which adorn it, does not offend in this respect, because the embossing serves to give rigidity to the metal without interfering with its defensive qualities. The same may be said of the barding shown on the Frontispiece, but on Plate IV the loss of dignity in line, and the embossed hemisphere—which, for its purpose, should be smooth—show the beginning of the decay in constructional skill. The highly ornamented pageant armour made for the Elector Christian II, now in the Dresden Museum, though extraordinarily perfect in workmanship, should be classed rather as the work of goldsmith or sculptor than as that of the armourer.

CHAPTER VI

In the practice of any of the crafts, or applied arts as they are now called, the surest and most manifest signs of decadence are to be found in two aspects of that craft. The first of these is that which refers to the material used. With regard to armour this consideration is faithfully adhered to in most examples of the armourer’s work up to the end of the fifteenth century; but by the beginning of the sixteenth century we find the craftsman becoming wearied of his technical perfection and the simplicity and constructional dignity which invariably accompanies such perfection. His efforts are now directed to fashioning his metal into such forms as in no way suggest his material, but only show a certain meretricious skill in workmanship. Fig. 41 shows a very favourite form of this artistic incoherence. The defensive properties of the helmet are in no way increased, but rather are annulled by presenting hollows and projections where before a smooth surface existed. It is superfluous to point out the grotesque and bizarre effect of this human face in metal.[32] Another instance of this wilful disregard of material is to be noticed in those suits which imitate the puffed and slashed dress in fashion for civilian wear during the sixteenth century. Many of these suits exist in English and European armouries, which proves that they were popular, but to the true craftsman there is something degrading in the efforts of the expert ironworker, expending his energies, not to produce a finely constructed piece of work, but rather to imitate the seams and pipings of the work of a tailor or dressmaker; and, however much we may admire his technical skill, we must, perforce, place his artistic aspirations side by side with the ‘grainer and marbler’ who was so conspicuous a factor in domestic decoration in the middle of the nineteenth century. Fig. 42 shows this decadence carried to its furthest pitch. By the middle of the sixteenth century the Renaissance, which had been, in the first instance, the birth of all that is best in European art and craftsmanship, became a baneful influence. The expert painter, having mastered the intricacies of his art, turned them into extravagant channels and exaggerated action; foreshortened figures and optical illusions took the place of the dignified compositions of the earlier period. Nor could the crafts escape this deadly poison. To the credit of the craftsmen we may hope that the luxurious indulgence and ostentatious display of the princely patron was the cause of decadence in the crafts, rather than the inclination of the workers themselves. Still the fact remains that, as soon as the plain and constructionally sound work began to be overspread with ornament, architecture, metal-work, wood-carving, and all the allied arts began to be debased from their former high position. With the decoration of armour its practical utility began to decline. It must be admitted, however, that one reason for the decoration was that armour was, by degrees, less and less used for war and only retained for pageant, joust, and parade in which personal display and magnificence were demanded.

Fig. 42. Puffed suit, sixteenth century. Vienna.[33]

Fig. 43. Casque after Negroli, sixteenth century. Paris.

The engraved and inlaid suits of the late sixteenth and seventeenth centuries, although they offend the craftsman’s eye as does the decorated bicycle of the Oriental potentate to-day, do not transgress that important law, on which so much stress has been laid, of offering a glancing surface to the opposing weapon. It is when we come to the embossed suits with their hollows and projections that we find the true character of armour lost and the metal used only as a material for exhibiting the dexterity of the workman without any consideration for its use or construction. This interference with the glancing surface is noticeable in the suit illustrated in Fig. 42, but even here there is some excuse, in that the designer had reason for his embossing of the metal—if the imitation of the puffed suit was to be carefully portrayed. The same, however, cannot be urged for those suits which are simply covered with ornament with no purpose, little meaning, and less composition or design. If we set aside our opinions as to the suitability of the ornament, we are compelled to admire the wonderful technical skill which produced such pieces as the suit made for King Sebastian of Portugal by Anton Pfeffenhauser of Augsburg, and now in the Madrid Armoury. Here every deity of Olympus, the allegorical figures of Justice, Strength, and the Cardinal Virtues, crowd together with Navigation, Peace, and Victory; Roman warriors fighting with elephants are found among Amorini, Satyrs, and Tritons; while every inch of the metal not devoted to this encyclopaedia of history and legend is crowded with foliage and scroll-work of that debased and unnatural form which has become the branding mark of this period of the Renaissance.

It will be sufficient to give one example of this prostitution of art and craftsmanship. This helmet after Negroli (Fig. 43), and a similar example, signed by Negroli, at Madrid, show how the canons of the armourer’s craft were ignored at this period. It is true that the casque still provides a metal covering for the head, and that the comb gives an additional protection to the skull, but when we examine the embossed figures at the side—and marvellously good the embossing is—we find lodgements for the sword or spear which would most certainly help to detach the helmet from its wearer. As to the comb, it may fairly be cited as an example of all that is artistically worst in the late Renaissance. Its technical merits only emphasize this. The warrior is laid on his back to suit the required shape of the helmet, and to give point to his position his hair is held by two figures whose attributes seem to suggest that intercrossing of birds, beasts, and fishes which delighted the decadent mind of the period. The figures are human to the waist and end in a dolphin’s tail. Angels’ wings spring from their shoulders and leopards’ claws from the junction of tail and waist. Not content with this outrage to the dignity of art, the craftsman ends his warrior in an architectural base which has not even the slight merit of probability which the tail of the merman might offer. In short it is an example of technical skill at its highest, and artistic perception at its lowest point. The shield from the Vienna collection (Fig. 44) is another example, like King Sebastian’s suit, of meaningless decoration. The strap work does not in any way follow the lines of the shield, and the female figures seem to be introduced only to show that the craftsman could portray the human form in steel as easily as he could the more conventional ornament.

As the armourer, weary of constructional skill, turned to ornament as a means of showing to what further extent his powers could expand, so, with this change in his point of view, his constructional skill itself declined. The headpiece, which in the golden age of the armourer was forged in as few pieces as possible, is in the late seventeenth century made of many pieces, as the art of skilful forging declines. The ingenious articulations of the soleret are changed, and the foot is cased in plates which, overlapping only in one direction, preclude the easy movement of the wearer. The fine lines of leg and arm defences, which in the fifteenth and sixteenth century follow the shape of the limbs, give place to straight tubular plates which can only be likened to the modern stove-pipe. The grace and symmetry of the Gothic suit shown on Plate VIII, especially the leg armour, exemplify this merit of the best period of armour, while the suit made for Louis XIV, and the gilt suit of Charles I in the Tower, offend in the opposite direction. Another sure indication of the decadence of the craftsman is to be found in the imitation of constructional detail with no practical purpose. Examples of this may be seen in late seventeenth-century armour, where a single plate is embossed to represent several overlapping plates or lames, and also in the plentiful use of ‘clous perdus’ or false rivets which are scattered broadcast on some suits in places where no rivets are needed.

To turn from the degradation of the simplicity and constructional perfection of armour to the reasons which led to its gradual disuse, we find that, after the Gothic period, armour became heavier, partly because of the shock tactics in vogue on active service and partly because, in the case of jousting armour, strength and great weight were needed to protect the wearer from vital injury, and partly because the improvement of firearms necessitated extra defence. The temper of the metal used was such that it would resist a pistol shot, as we have noticed in Chapter III; and on examining the surface of the metal we find, as in the Pembridge helm, that it is of so fine a texture that a modern knife will not leave a scratch when testing it. Therefore we must regard the weight of armour as one of the chief reasons for its disuse. Again, military tactics necessitated forced marches and longer expeditions than before; or at any rate it was discovered that when engaging in long expeditions the troops were chafed and hindered by their armour. It is somewhat curious to note that as the leg was the first part of the body to be armed with plate, so the leg armour was the first to be discarded. The jambs were the first pieces to go, and were replaced, in the case of the mounted man, by thick buff leather boots. The tassets were prolonged to the knee or—to describe this portion of the armour in a different way—the cuisses themselves were formed of riveted lames and the tassets discarded.

The helmet at the latter end of the seventeenth century is generally open and of the burgonet type. The breastplate is usually short and projects downwards at the lower portion after the fashion of the ‘peascod’ doublet of civilian wear. As early as 1586, at the siege of Zutphen, we find officers discarding their armour and keeping only the cuirass. From the Hatfield MSS. we learn that a penny a day was allowed to each soldier in 1590, over and above his pay, for the wearing and carriage of his armour, because it had become the custom for the troops to give their accoutrements to the baggage-carriers when on the march: ‘a matter both unseemly for soldiers and also very hurtful unto the armour by bruising and breaking thereof, whereby it becometh unserviceable.’ In Cruso’s Militarie Instructions for the Cavallrie (1632), we find that the arquebusiers had wholly left off their armour in favour of buff coats. Turner’s Pallas Armata (1670) mentions the armour of officers as ‘a headpiece, a corslet and a gorget, the captain having a plume of feathers in his helmet, the lieutenant not’. Further on we read, ‘now the feathers you may peradventure find, but the headpiece for the most part is laid aside.’ Fig. 45 shows that half armour was still worn during the Commonwealth, but by the Restoration very little was retained except for ceremonial use. As far as can be gleaned from contemporary letters and histories, Charles I never wore either the somewhat cumbrous gilt suit which is shown at the Tower or the more graceful half suit of blued steel in which Vandyke represented him in his equestrian portrait. All the metal defence we can be sure he actually wore is a steel broad-brimmed hat covered with velvet. The headpiece used by the cavalry during the Civil War is of the same type as No. 11 on Plate IV, a variety of the burgonet with a movable nasal. The breastplate continued to be worn during the wars of Marlborough, but that, too, was discarded when the efficacy of the musket proved its uselessness. The last survival of plate armour is to be found in the gorget. This became smaller as the uniform was changed, and in the end was simply a small crescent of brass hung at the neck. It was worn by infantry officers up to the year 1830, at which date it was given up in England.

The last official use of full plate armour was at the Coronation of George IV, when the King’s Champion, Dymoke, entered Westminster Hall and threw down the gauntlet to challenge those who disputed the King’s right to the crown. The suit worn on this occasion belonged originally to Sir Christopher Hatton, Captain of the Guard to Queen Elizabeth, and was made by Jacobe,[34] whose designs for armour have been referred to in Chapter III. The suit is now in the Guard Room at Windsor. The Guardia Nobile of the Pope still wear the picturesque half armour of the sixteenth century. The cuirass and helmet of the Household Cavalry of the present day are not survivals, for they were introduced at the time of the Coronation of George IV.

The study of defensive armour and weapons must of necessity need much careful comparison of examples and investigation of documentary evidence, but, even when undertaken only superficially, it will add greatly to the interest of modern history and of the arts of war. Costume can only be studied from pictorial and sculptured records, but in the case of armour we have, after a certain period, actual examples not only of historical but also of personal interest. With modern methods of arrangement and with the expert care of those most learned in this subject these examples will be an ever-present record which may be examined with more interest than might be bestowed upon many branches of the applied arts; because, in addition to the interest centred in the personality of the wearers, we have the sure signs of the master-craftsman which are always evident in good craftsmanship, and, not infrequently, the sign-manual of the worker himself.

CHAPTER VII

The Sword. At the time of the Conquest the sword was straight, broad in blade, two-edged and pointed. The Quillons were straight and the grip ended in a Pommel which, as far as we can judge from illustrated records, was square, round, lozenge-shaped or trefoiled (Fig. 46). There is not much change in the general lines of the sword during the twelfth century except in the form of the pommel.

In the thirteenth century the point, instead of starting abruptly at the extreme end of the blade, is of a more gradual form, showing that the use of the sword for thrusting was more general than in the previous centuries. The Grip seems to be very short for the proper balance of the weapon, if we may judge from those shown on Plate III, 1, 2, 3.

The quillons curve upwards towards the point and the pommel is frequently decorated with the badge or arms of the owner. The symbol of the Cross is frequently found on the sword-pommel. At this period the handle and scabbard are frequently enriched with ornamental metal-work set with gems, as we find on the monument of King John in Worcester Cathedral. The cruciform shape of the sword-hilt continues through the fourteenth century without much radical change in its construction, but in the fifteenth century we find the ‘Pas d’âne’, which is formed of two rings curving above the quillons on each side of the Ricasso, or squared part of the blade above the hilt (Fig. 47). It is usual to describe the sword as it is held for use in hand; that is with the point as the highest part and the pommel as the lowest. After the fifteenth century sword-play began to be studied as a science, and we find that, besides being used for offensive purposes, the sword-hilt was so designed as to be a defence in itself. From this we get all the guards and counterguards, which are so varied and intricate that it would require more space than is at our disposal to treat of them with any degree of completeness.

The type of sword that was thus developed by practice in its use was purely for thrusting purposes. The sword for cutting alone is generally simpler in form. The Cutilax, Falchion, Dussack, and Cutlas are all weapons of this order and generally have a simple hilt. The modern Claymore is really an adaptation of the Italian Schiavona (Fig. 48), and is in no way derived from the Claymore proper, the Two-hand sword of the Middle Ages. This great weapon, often as much as 6 feet in length from point to pommel, was used by foot-soldiers, and special military arrangements were made for the space given to its users, who required a good sweeping distance between each man (Fig. 49). The Hand-and-half sword is a variety of cross-hilted sword, in which the grip is sufficiently long for two or three fingers of the left hand to be used to assist the right hand in delivering a swinging cut.

The early Dagger is of much the same form as the sword; it was worn on the right side with the sword on the left. One variety of the dagger was called the Miséricorde. It was finely pointed and, as its name grimly implies, was intended to penetrate the joints of the armour to give the coup de grâce to the fallen knight. The Main-gauche is also of the dagger order, but has a broad knuckle-guard and long straight quillons. It was used in conjunction with the rapier in duels with the point upwards, more as a means of warding off the sword-thrust than for actual stabbing. The Anelace and Cinquedea are broad-bladed short weapons used for stabbing only. The Baselard was the short sword carried by civilians in the fifteenth century.

Of staff weapons the principal is, of course, the Lance. At the time of the Conquest and up to the fourteenth century the shaft of the lance was of even thickness with lozenge- or leaf-shaped point. During the fourteenth century we find the shaft swelling just above the grip and then tapering below it. Plate XI, 14, shows the lance provided with a vamplate or shield, which protected the hand and made the right gauntlet unnecessary. Tilting lances are sometimes as much as 15 feet in length, and one specimen in the Tower weighs 20 lb. An engraving by Lucas Cranach (1472-1553), which depicts a tourney or mêlée of knights, shows the combatants preceded by squires on horseback who support these weighty lances till the moment of impact, when, it is presumed, they moved aside out of danger. The lance-point was sharp for active service, but for tournaments it was supposed to be blunted. This practice, however, was so often neglected that ordinances were framed enjoining the use of the Coronal or trefoiled button, which is shown on Plate XI, 15.

The other long-shafted staff weapons may be divided into those for stabbing and those for cutting. The Gisarme is a long-handled weapon which some writers consider to have been much the same as the Pole-axe. From Wace we learn that it was sharp, long, and broad.[35] It was in all probability a primitive form of the Bill. This was also a broad-bladed weapon and was used only by foot-soldiers. It seems to have been evolved from the agricultural scythe. The Godendag was the name given by the Flemings to the Halbard. It had an axe-blade with curved or straight spikes at the back and a long point to terminate the shaft. In this detail it differed from the pole-axe. The halbard proper was used as early as the thirteenth century and appears in the designs from the Painted Chamber at Westminster figured by Stothard.[36] From the seventeenth century onwards it was used only for ceremonial purposes and was richly decorated. It was carried on parade by infantry drum-majors in England as late as 1875. It was much favoured by the Swiss, who armed the front rank of the footmen with this weapon. Those used for parade purposes are elaborately engraved on the blades, while the shafts are often covered with velvet and studded with gilded nails. These ornate weapons are used still by the Gentlemen-at-Arms on State occasions. The Voulge is a primitive weapon evolved from an agricultural implement of the same class as the hedging bill in use at the present day. The Lochaber axe is of much the same form; its distinguishing feature being the hook at the top of the shaft, which was used in scaling walls. The Glaive is also a broad-bladed weapon, but where the bill and gisarme are more or less straight towards the edge, the glaive curves backwards. It is often to be found richly engraved for show purposes. In French writings the word glaive is sometimes loosely used for lance or sword.

The stabbing or thrusting long-shafted weapons include the Lance, Spear, and Javelin. After these the most important is the Pike. This is very similar to the spear, but was used exclusively by foot-soldiers. In the seventeenth century it was carried by infantry interspersed among the arquebusiers. There are several works on pike-drill and treatises on its management. Lord Orrery, in his Art of War, comments on the differences in length and recommends that all should be 16½ feet long. The shaft was made of seasoned ash and the head was fastened with two cheeks of iron, often 4 feet long, which ran down the shaft to prevent the head being cut off by cavalry. At the butt-end was a spike for sticking into the ground when resisting cavalry. In a treatise entitled The Art of Training (1662) directions are given that the ‘grip’ of the shaft should be covered with velvet to afford a sure hold for the hand. This grip was called the Armin. There are also suggestions that a tassel should be fixed midway to prevent the rain running down the shaft and so causing the hand to slip. When we consider that the pikeman had to keep the cavalry at bay while the arquebusier was reloading—a lengthy process—we can understand the importance of these regulations. The pike was carried by the colour-sergeants in the British Army at the beginning of the nineteenth century, and was last used in the French Army in 1789. The Spontoon is a species of half-pike, which was carried by the colour-sergeants in the British Army up to the end of the eighteenth century, if not longer. The Spetum and the Ranseur are often confused. The names are usually given to those weapons which have sharp lateral projections fixed at a more or less acute angle to the point. They could not be used for cutting, but used for thrusting they inflicted terrible wounds. The Partizan is somewhat of the same order, but is known best in museums in its decorated form as used in ceremonial parades. These show-weapons were used by the Judge’s guard in Oxford up to 1875, and are still carried by the Yeomen of the Guard on State occasions.
