Railroads: Rates and Regulations

The discussion of the nature of railroad expenditure may be concluded by a comparison of the net effects of the developments of the last few years; that is to say, of steadily expanding costs of operation and of slowly and tardily rising rates chargeable for service on the one hand, as over against the results obtained by mechanical improvements and increasing economy of operation coupled with growth of tonnage, on the other. The average cost of transportation has greatly increased. This, according to the statistics of the Interstate Commerce Commission, is shown upon the diagram herewith by the middle curve.[62] The average cost of running all trains per mile, which had fallen from 96 cents in 1891 to 91.8 cents in 1895, rose to $1.07 in 1900, and in 1911 increased by more than one-third, to $1.54 per mile. Against this should be set the fact that while the trains thus cost more to haul per mile, their paying load has increased in somewhat smaller proportion. This is shown by the upper curve on the diagram above mentioned. For freight trains the increase has been from $1.65 to $2.89 per mile. Passenger revenues per train mile have increased less rapidly. This follows from the well-known fact that freight rates have been increased, while passenger rates have not changed for the better during this period; and also that economies in concentration of traffic are necessarily confined to the carriage of freight. The immense gain in trainloads has probably been the main element, among these, as already observed.

Among other things this diagram also brings out the effect upon revenue of the substantial rate increases after 1900, coupled with the elimination of rebate losses. It will be observed how sharply the upper curve of revenue per train mile slants upward after 1899, by comparison with the lower line denoting cost. The same thing apparently occurs again after the set-back of 1907.

The interrelation between these various factors may be more readily shown by confining our attention to the period during which a practically uninterrupted development of business ensued, thus eliminating the confusion due to the four years of depression after 1893. The data on our various charts for the years 1898-1906 demonstrate that during this period the ton mileage, measuring the freight traffic handled, has practically doubled. To transport this doubled tonnage, a growth in freight train mileage of only eighteen per cent. was necessary. This was due, of course, to the notable concentration of train loading, already described, as well as to a density of traffic per mile of line almost sixty per cent. greater. As a consequence of these economies in operation, the revenue per freight train mile has increased by about fifty per cent.; while the average cost of running all trains per mile has grown less rapidly, namely, by 42 per cent. Had we data for freight trains alone it would surely be lower than this. In the meantime during this period of eight years, the rate of return in revenue per ton mile received, remained practically unchanged.[63] From all of which it would appear that even despite all these confusing factors, the law of increasing returns, so far at least as 1898-'06 was concerned, was making itself appreciably felt.

Attentive consideration of the available figures, especially as shown by diagram on page 97, shows apparently that the various economies in operation, heavier trainloads and the like, have not since 1906 yielded any greater profit from mere operation, with the ever increasing volume of business. In other words, the increase in the margin between cost of operation and revenue per train mile,—measuring profitableness per unit of movement—has not kept pace with the augmentation of the size of that unit,—the trainload. Thus it follows, as one would expect, even making allowance for all changes in rates, wages and other expenses, that the law of increasing returns as applied to railroads, does not arise primarily from economic considerations as to mere physical operation. The law originates primarily in the fiscal conditions attaching to the heavy capital investment,—the fact, namely, that fixed charges up to a given point of saturation tend to remain constant, absolutely; but become proportionately less, therefore, as the volume of business expands. From this fact, therefore, rather than because of any marked economies of large-scale production, may it be affirmed that railroads offer a notable example of the law of increasing returns. The important bearing of this distinction will appear in due time in connection with the problem of the determination of reasonable rates. Added significance, also, is given to the relation between the cost of new capital, measured by the rates of interest on bonds and dividends on stocks, and the supply necessary to provide adequate extensions and improvements in future.

Appendix:

The subjoined chart, reproduced by the Railway Age Gazette from a bulletin of the Bureau of Railway Economics, brings out forcibly the manner in which, within the short time limits of full utilization of plant, a large increase of business can take place without a commensurate growth of expenses. The phenomenon for railroads is of course cyclical. Annually, as here indicated for 1911, the second half of the year is marked by a much heavier movement of traffic, principally, of course, the crops. But expenses never rise in proportion. This is most evident for the eastern group of roads, as here shown. This causes the net revenue curve, also, to vary much more than in proportion to the volume of traffic, in consequence.
